Features

Features

  • •Resolution of 0.1° (Light OS), Resolution of 0.01° or 0.1° (Full OS), Resolution of 0.001°, 0.01°, or 0.1° (Master)
  • •Easy °F to °C unit switching
  • •Multi-point calibration
  • •Durable anodized aluminum body
  • •Data Logging (USB cable available upon request)
  • •Long Battery Life
  • •Useful for custody transfers, temperature baths, references ,temperature calibration for flow meters, thermowells, provers, distillations, melting point tests, and flash point tests.
  • •Useful in the Petroleum, Pipline, Pharmaceutical, Food, and many more labratory enviroments.

The most durable and cost-effective digital contact thermometer (DCT), portable electroinc thermometer (PET) available on the market

Specifications

Specifications

  • Explosive Proof Certification: CSA C/Us 3,7VDC 0,1A Class 1, Zone 1 A/Ex ia IIC T4
  • Average Calibrated Accuracy: ±0.080°F, 32°F — 300°F (±0.048°C, 0°C — 150°C)
  • Battery Life: 1000 hours without backlight. 25 hours with backlight.
  • Battery: Single AA Battery.
  • Ambient Operating Temperature: -40°F — 122°F (-40°C — 50°C)
  • Display: LCD, amber backlight with trend indication arrows, low battery, and fault indication
  • User Functions: Autosample function with averaging. Temperature List with averaging function. Switchable between °F and °C. User selectable auto-off timer. Selectable Resolution.
  • Unit Construction: Milled Alumnium body. Durable display window with membrane switches.
  • Probe Construction: Stainless steel temperature probe in either 3/4" or 1" diameters.
  • Probe Type: 1000Ω, Class A Platinum RTD. Immersion depth 4"  (11cm).
  • Time Constant: 7s, 63.2% response to temperature change. Circulated water bath.
  • A/D resolution: 20 bits
