Features

Features

Resolution Options:
0.1° (Light OS)
0.01° or 0.1° (Full OS)
0.001°, 0.01°, or 0.1° (Master)
Units:
Easy °F to °C unit switching
Calibration:
Multi-point calibration capability
Construction:
Durable anodized aluminum body
Data Logging:
USB data logging capability (USB cable available upon request)
Battery Life:
Long battery life for extended field use
Typical Applications:
Custody transfer, temperature baths, reference measurements, temperature calibration for flow meters, thermowells, provers, distillations, melting point tests, and flash point tests
Industries:
Petroleum, pipeline, pharmaceutical, food, and various laboratory environments
Product Highlight:
The most durable and cost-effective Digital Contact Thermometer (DCT) / Portable Electronic Thermometer (PET) available on the market

Specifications

Specifications

Explosive Proof Certification:
CSA C/US 3.7VDC 0.1A
Class I, Zone 1 A/Ex ia IIC T4
Average Calibrated Accuracy:
±0.080°F from 32°F to 300°F
(±0.048°C from 0°C to 150°C)
Battery Life:
Up to 1000 hours without backlight
Approximately 25 hours with backlight enabled
Battery:
Single AA battery
Ambient Operating Temperature:
−40°F to 122°F
(−40°C to 50°C)
Display:
LCD with amber backlight, trend indication arrows, low battery indication, and fault indication
User Functions:
Auto-Sample function with averaging
Temperature list with averaging function
Switchable between °F and °C
User-selectable auto-off timer
Selectable resolution
Unit Construction:
Milled aluminum body with durable display window and membrane switches
Probe Construction:
Stainless steel temperature probe available in 3/4" or 1" diameters
Probe Type:
1000Ω, Class A Platinum RTD
4" (11 cm) immersion depth
Time Constant:
7 seconds (63.2% response to temperature change) in a circulated water bath
A/D Resolution:
20 bits
