Display:
Amber backlit LCD with 0.45" characters, trend indication arrows, and low battery and fault indicators.
Construction:
Stainless steel temperature probe and sensor. Electronics and display housed in a 4" × 2" × 7" anodized aluminum enclosure with durable display window, graphics, and membrane switches.
Weight:
Weight depends on cable length and probe style; 75 ft, 3/4" diameter probe unit weighs 3.9 lb.
Temperature Resolution:
Resolution to 0.1°.
Calibrated Accuracy:
±0.080°F from 32°F to 300°F; ±0.048°C from 0°C to 150°C.
Time Constant:
7 seconds in a circulated water bath (63.2% response to temperature change).
Sensor:
100 ohm, Class A platinum RTD with 4" (11 cm) immersion depth.
Battery:
Energizer Ultimate Lithium L91 intrinsically safe rated AA battery. Battery life (depending on use) 25–150 hours. Operating range −40°C to 60°C (−40°F to 140°F).
Typical Applications:
Custody transfer, temperature baths, reference measurements, temperature calibration for flow meters, thermowells, provers, distillation, melting point tests, and flash point tests.
Industries:
Laboratory, petroleum, pipeline, pharmaceutical, food, and related industries.
Certifications:
Intrinsically safe for use in Class I, Division I Groups A, B, C, & D; Class I, Zone 0, Group IIC hazardous locations. CSA C/US A/Ex ia IIC T4.
``
